Bora CKASE2 Set Kochfeldabzugssystem

Description

Kochfeldabzug und zentraler Bestandteil des modularen Kochfeldabzugssystems BORA Classic 2.0, komplettes Abzugssystem vom Kochfeldabzug bis zum Sockel (inkl. Schalldämpfer, Lüfter und Kanalteile), je nach Abluft- oder Umluftvariante komplettieren weitere Komponenten (z.B. Geruchsfilter, Mauerkasten) den Abzug, mit verschiedenen Kochfeldern individuell kombinierbar. Zentrales Touch-Bedienfeld zur Steuerung des Kochfeldabzugs und der Kochfelder, Farbwechsel am Bedienfeld zur Unterscheidung zwischen Kochfeld- und Abzugssteuerung

Product benefits

  • Abzugsautomatik
  • Nachlaufautomatik
  • Powerstufe
  • Filterstands- und Filterserviceanzeige (nur bei Umluft)
  • Bediensperre
More product information
BORA Classic 2.0 with flex induction and Tepan stainless steel grill, top view

BORA Classic 2.0: modular, flush-mounted, intuitive

With the Classic 2.0, the cooktop extractor and cooktops are put together individually: flex induction, induction, induction wok, radiant heating, gas or Tepan stainless steel grill. Cooktop and extractor sit completely flush, and in standby the controls are almost invisible.

Everything is controlled via the central touch control directly below the inlet nozzle, and the extraction power adjusts automatically to the cooking process. The flex induction zones are particularly large at 230 × 230 mm and can be bridged to 230 × 460 mm. With the inset frame, an almost flush installation is possible even in laminate worktops.

BORA cooktop extractor drawing cooking vapours straight down at the hob

How the BORA cooktop extractor works

Cooking vapours rise at no more than about one metre per second. The BORA extractor draws them downwards directly at the cooktop at around four metres per second. The resulting cross-flow is stronger than the rising steam and pulls odours and grease particles into the system before they spread through the room.

There, a grease filter cleans the air, and in recirculation mode an activated charcoal odour filter as well. Without a hood above the cooktop, the view stays clear and there is room for lighting above the kitchen island. The moving parts of the extractor can be removed and cleaned in the dishwasher.

Product properties

Energy Class: A+
Exclusive Range: BORA Lüftungstechnik
Motor: Yes
Product Line: Bora Classic 2.0
Smart Home: No
Ventilation Mode: Convertible, Exhaust Air, Recirculated Air
Scope of delivery: 1x Classic Kochfeldabzug CKA2, 1x Flachschalldämpfer USDF, 1x Sockellüfter EC ULS, 1x Ecotube Bogen 90° flach vertikal EFBV90/1, 1x Ecotube Übergang flach rund gerade EFRG/1, 1x Ecotube Übergang flach rund Versatz 110 mm EFRV110/1, 1x Ecotube Flachkanal mit Steg 375 mm EFS375/1, 2x Ecotube Kanalverbinder flach EFV/1, 7x Ecotube Dichtung flach EFD/1, 1x Ecotube Dichtung rund ERD/1,
Manufacturer:
Product number: 788764
GTIN: 4251731202447
MPN: CKASE2

About the manufacturer

BORA is revolutionizing cooking with innovative cooktop extractors seamlessly integrated into the induction cooktop. Explore the Professional, Classic, Basic, Pure, and X Pure series, featuring cutting-edge technology and effective ventilation solutions.

  • BORA Lüftungstechnik GmbH
  • Rosenheimer Straße 33
  • 83064 Raubling
  • Phone: +49 (0) 8035 / 9840-0
  • E-Mail: support@bora.com
  • Website: www.bora.com

Learn more

Frequently asked questions

With extraction, the extracted air is routed outdoors through a duct system with a wall box via the outside wall, roof or basement. With recirculation, a grease filter and an activated charcoal odour filter clean the air, which then flows back into the room. All BORA cooktop extractor systems are available in both versions.

Recirculation is easier to install and well suited to rented flats, kitchen islands and passive or low-energy houses. In return, the odour filter has to be changed regularly and the humidity stays in the room. Extraction is low-maintenance and takes moisture outside, but requires an opening in the building and can cost heating energy in winter.

No. As extraction solutions are planned individually, the duct system (BORA Ecotube) and the wall box are not included with the cooktop extractor system. They are ordered separately to suit the installation situation.

That depends on the system: for the Pure family and the Basic after around 150 operating hours or one year. The flexible air cleaning box of the modular systems lasts around 300 operating hours (about 1.5 years), the activated charcoal filters of air cleaning box 3 around 600 operating hours (about 3 years). The control panel indicates in good time when a change is due.

The automatic run-on keeps the extractor running at a low level for about 20 minutes after cooking. This dries the activated charcoal so it can bind odours better.

Extraction mode creates negative pressure. Without a sufficient supply of fresh air, flue gases from a fireplace could be drawn into the room. For this, BORA offers the UFKS window contact switch, which only enables the extractor when a window is open. Please clarify the installation situation in advance with your kitchen planner and the responsible chimney sweep.
